| Display | 8 high-efficiency digits h = 13 mm |
| Incremental Encoder input signals | 2 square waves with phase displacement of 90° ± 5° and zero ref. 5 Vdc or 12 Vdc |
| Power supply | 230 Vac ± 10% – 50/60 Hz 40 mA 110 Vac ± 10% – 60 Hz 80 mA 24 Vac ± 10% – 50/60 Hz 350 mA |
| Memory | permanent for configuration and “user” settings (last data operating memory) |
| Available resolutions | 200 – 100 – 50 – 20 – 10 – 5 – 2 – 1 – 0.5 μm 1° – 0.5° – 0.2° – 0.1° – 0.05° – 0.02° – 0.01° – 0.005° – 0.002° – 0.001° |
| Download Brochure ↓ | |
| |
| Display | 8 high-efficiency digits h = 13 mm |
| Incremental Encoder input signals | 2 square waves with phase displacement of 90° ± 5° and zero ref. 5 Vdc or 12 Vdc |
| Absolute (SSI) encoder input signals | RS-422: Clock+, Clock-, Data+, Data- |
| Power supply | 230 Vac ± 10% – 50/60 Hz 40 mA 110 Vac ± 10% – 60 Hz 80 mA 24 Vac ± 10% – 50/60 Hz 350 mA |
| Memory | permanent for configuration and “user” settings (last data operating memory) |
| Available resolutions | 200 – 100 – 50 – 20 – 10 – 5 – 2 – 1 – 0.5 μm 1° – 0.5° – 0.2° – 0.1° – 0.05° – 0.02° – 0.01° – 0.005° – 0.002° – 0.001° |
| Options | serial output RS-232 relay outputs static relays AC – static relays DC absolute (SSI) encoder input |
| Download Brochure ↓ | |
