| Resolution Line Driver | 5 µm |
| Resolution absolute measure | I µm- 0.1 µm |
| Accuracy grade | ± 2.5 µm standard ± 1 µm high accuracy |
| Max. traversing speed | 60 m/min |
| Measuring length | 170, 220, 270, 320, … mm |
| Power supply | 5 Vdc ± 5% or 10 + 28 Vdc ± 5% |
| Serial interface | SSI-BiSS C (unidirectional) |
| Protection class | IP 54 standard IP 64 pressurized |
| Download Brochure ↓ | |
