AEN 58
Absolute encoder Ø 58 mm

Overview

  • Compact-design absolute rotary encoder, based on optical principle.
  • Singleturn resolution up to 17 Bit.
  • Multiturn resolution up to 12 Bit.
  • High accuracy and stability of signals.
  • Linearity ± ½ LSB (± 1 LSB for resolutions > 13 Bit).
  • Serial interface (SSI-BiSS, with or without 1 Vpp analog signal), Fieldbus (CANopen, Profibus, DeviceNet) or Parallel.
  • Several flanges available.
  • IP 67 protection class available.
  • Aluminium flange and body.
  • Axial or radial output (with connector or cable).
  • High rotational speed (up to 12,000 rpm).
  • Diagnostics: warning, LED indication, temperature measurement, alarm bit.

Models
